Description
The DAYLIFF DDW submersible pump range are centrifugal submersible pumps designed for small scale drainage, irrigation, fountain and water transfer applications. Two versions are available, the standard S version with open impeller for lightly turbid water and the vortex version for water with higher silt loads.Pump construction is of high strength engineering plastic for the pump casing, suction base and impeller and an external float switch is provided for automatic pump control. All pumps are supplied with 5m of waterproof power cable and a union connected outlet suitable for threaded or hose connection. MOTORPumps are provided with intergral non-overloading induction motors designed for continuous operation. A thermal cut-out is provided in the motor winding to protect against pump overload and the pump can be connected directly to the mains power supply through a 10A fuse or MCB.MotorEnclosure ClassX8Voltage1 X 240VInsulation ClassBSpeed2900rpmOperating ConditionsPumped LiquidThin, clean, chemically non aggressive liquids without abrasive particles or fibresMaximum Fluid Temperature+35CMaximum Operating Depth8MPump InformationModelDDW 750VPower (kW)0.75Maximum Operating Current (A)5.2Outlet1 1/4"Dimensions (mm) - H350Dimensions (mm) - W250Weight (kg)6
