Description
The Dayliff DWY range of portable submersible pumps are designed for well pumping and drainage of clean water containing minimal impurities for domestic and small scale water supply applications. They are of closed impeller type, all major components being manufactured from cast aluminium. All models are supplied with 8m of cable and level switch for automatic operationMOTOR Pumps are supplied with two pole single phase squirrel cage motors with integral thermal overload protection and can be directly connected to the mains through a 10A fuse or MCB (13A for 1.5kW motor) Enclosure Class:IP68 Insulation Class:F Voltage:1x240 Speed:2850rpm OPERATING CONDITIONS Pumped Liquid: Thin, clean, chemically non-aggressive liquids Max. Fluid Temperature: +40°C Max. Ambient Temperature: +40°C Max. Immersion Depth:10m Max. Particle Size: 1.1kW, 3.3mm, 1.5kW, 5.5mmMotorEnclosure ClassIP 68Voltage1 X 240VInsulation ClassFSpeed2900rpmOperating ConditionsPumped LiquidThin, clean, chemically non aggressive liquids without abrasive particles or fibresMaximum Fluid Temperature+40CMaximum immersion depth10Pump InformationModelDWY 550Power (kW)0.55Maximum Operating Current (A)4.2Outlet1 "Dimensions (mm) - H235Dimensions (mm) - W220Weight (kg)10
